Overview

The TOXU TX-S65-4CH-SNB is a 4-channel compact GNSS anti-jamming terminal designed for small and medium-sized UAVs, unmanned vehicles, and industrial users requiring reliable satellite navigation performance.

The terminal integrates antenna array, anti-jamming components, and GNSS receiver functions into one miniaturized all-in-one design, providing a lightweight solution for autonomous navigation applications.

TX-S65-4CH-SNB supports BDS B1C, B1I, and GPS L1 satellite navigation signals. The compact structure, low power consumption, and integrated design make it suitable for applications with strict size and weight requirements.

Key Features

4-Channel Anti-Jamming Architecture

The 4-channel design provides GNSS interference suppression capability with single interference SIR ≥95dB, double interference SIR ≥85dB, and three interference SIR ≥80dB.

Compact Miniaturized Structure

The compact 65mm × 65mm × 21mm enclosure design enables easy integration into small UAVs and lightweight autonomous platforms.

BDS/GPS GNSS Signal Support

Supports BDS B1C, B1I, and GPS L1 satellite navigation signals for reliable positioning applications.

Integrated GNSS Navigation Solution

The product combines antenna array, anti-jamming modules, and GNSS receiver functions into one compact terminal solution.

Low Power Consumption Design

With power consumption ≤6W and weight ≤130g, the terminal is suitable for size-sensitive navigation applications.

Technical Specifications

Dimension Drawing

The TX-S65-4CH-SNB features a compact enclosure design with dimensions of 65mm × 65mm × 21mm.

The lightweight structure supports M2 screw mounting and flexible integration into small UAVs and autonomous platforms.

Applications

• Small UAV Navigation Systems

• Drone Positioning Applications

• Unmanned Vehicles

• Industrial Autonomous Platforms

• GNSS Navigation Systems

System Integration

The TX-S65-4CH-SNB supports integration with flight controllers and autonomous platforms through TTL serial communication.

The terminal outputs navigation information through NMEA0183 protocol and provides flexible connection options according to different system requirements.

The SMA RF interface can be used for RF signal connection with compatible navigation equipment.

Why Choose TOXU

TOXU provides integrated GNSS and RF hardware solutions including GNSS terminals, anti-jamming solutions, GNSS antennas, and RF cable assemblies.

With professional RF engineering capability, OEM/ODM customization service, and manufacturing support, TOXU supports customers from prototype development to mass production.

Supported by IATF16949 and ISO9001 quality systems, TOXU provides reliable hardware solutions for industrial positioning and navigation applications.

FAQ – Frequently Asked Questions

Q1: What is TX-S65-4CH-SNB?

A1: TX-S65-4CH-SNB is a compact 4-channel GNSS anti-jamming terminal designed for small UAVs, unmanned vehicles, and industrial navigation systems.

Q2: Which GNSS signals are supported?

A2: It supports BDS B1C, B1I, and GPS L1 satellite navigation signals.

Q3: What is the anti-jamming capability?

A3: The terminal supports single interference SIR ≥95dB, double interference SIR ≥85dB, and three interference SIR ≥80dB.

Q4: Can TOXU provide customization?

A4: Yes. TOXU supports OEM/ODM customization including GNSS terminal optimization, hardware integration, and customized positioning solutions.
